Maxbright Display Media (Shenzhen) Co.,Ltd.
| Place of Origin: | Shenzhen, China |
|---|---|
| Brand Name: | Maxbright |
| Certification: | CE |
| Model Number: | M490EDCP-TS |
| Minimum Order Quantity: | 1 |
| Price: | Negotiable |
| Packaging Details: | Pearl cotton shock absorption + carton packing |
| Delivery Time: | 4~5 weeks |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100 sets / Month |
| NATIVE RESOLUTION: | 1080 X 1920 RGB | PIXEL PITCH: | 0.55926(H) X 0.55926(V) Mm |
|---|---|---|---|
| COLOR: | 8 Bits | HORIZONTAL FREQ: | 57.3KHz ~ 70KHz |
| INTERFACE: | VGA, HDMI | Name: | Outdoor Advertising LCD Screen |
| High Light: | Outdoor Advertising LCD Screens 49 Inches,Dual Face outdoor advertising lcd display,HDMI outdoor advertising lcd display |
||
49” High Bright Dual Face Outdoor LCD E-poster Model : M490EDCP-TS
LED Array Backlight Enhanced
Model: M490EDCP-TS
FEATURES:
Active Matrix TFT-LCD Display
High Brightness 2000-2500 nits, Sunlight Viewable
1920 x 1080 WUXGA Max. Resolution
Aspect Ratio: 9:16 in portrait mode enabled
Wide Viewing Angles 178 deg (L/R/U/D)
Wide operating temp range, -30 ～ 50o C
Media player box or mini Ind. PC for content playback
Waterproof IP65 enclosure
|
FEATURES:
Active Matrix TFT-LCD Display High Brightness 2000-2500 nits, Sunlight Viewable 1920 x 1080 Max. Resolution Aspect Ratio: 9:16 in Portrait mode enabled Wide Viewing Angles 178 deg. (L/R/U/D) Wide operating temp range, -30 ～ 50o C Media player or mini-PC for content playback Waterproof IP54 enclosure |
|||
|
Main Specs of 49” High Bright Outdoor LCD Totem
|
|||
| PANEL TYPE | a-Si active matrix TFT-LCD | ||
| ACTIVE AREA | 632.5 x 1096.2 mm portrait orientation | ||
| NATIVE RESOLUTION | 1080 x 1920 RGB | ||
| PIXEL PITCH | 0.55926(H) x 0.55926(V) mm | ||
| COLOR | 16.7 Million, 8 bits | ||
| HORIZONTAL FREQ. | 57.3KHz ~ 70KHz | ||
| VERTICAL FREQ. | 47Hz ~ 63Hz(DVB/PAL), 57Hz ~ 63Hz(NTSC) | ||
| BRIGHTNESS | 2000-2500 cd/m2, LED Backlight Enhanced | ||
| CONTRAST RATIO | 1100:1, Dynamic contrast ratio: 9000:1 | ||
| DIMMING | Auto-dimming by Light Sensor | ||
| VIEWING ANGLE | 89/89/89/89 | ||
| RESPONSE TIME | 12 msec typical | ||
| INTERFACE | VGA, HDMI | ||
| MEDIA PLAYER | Media Player (RK3288 Android OS ) (option) | ||
| REMOTE CONTROL | Support for Full OSD Features | ||
| OPERATING VOLTAGE | AC 100 ~ 240V 60/50Hz | ||
| POWER CONSUMPTION | 300W for 2000 nits, 380W for 2500 nits | ||
| STANDBY MODE | 3 Watt or less | ||
| ACCESSORIES | AC Power Cord, Remote Controller | ||
| HDMI, VGA cable x 1 | |||
|
OPERATING (option)
|
Media Player RK3288 Quad-core Cortex-A17 1.8GHz, 2GB DDR3, 32-64GB SD, 4xUSB ports, 1xRJ45 |
||
| 1 x HDMI, 2 X RS232, Android OS 5.1 | |||
|
DIMENSION WEIGHT |
1500(H) x 746(W) x 140(D)mm 78 Kg approx |
||
| Waterproof IP54 Enclosure | |||
| COOLING | By cooling fans controlled by MCU for outdoor | ||
| 600W Mini air-condition option for harsh outdoor | |||
| ENVIRONMENTAL |
Operating Temperature -10-45oC, Wide temp. -30-50oC (option) |
||
| Operating Humidity 10%-85% | |||
| Storage Temperature -30-60oC | |||
| Storage Humidity 5%-90% | |||
| WARRANTY | One Year | ||
